IMP120J 12m Self-Propelled Vertical Mast Lift with Jib

Mantall Heavy Industry Co., Ltd. is one of the leading manufacturers and suppliers of IMP120J 12m Self-Propelled Vertical Mast Lift with Jib in China. We warmly welcome you to buy discount IMP120J 12m Self-Propelled Vertical Mast Lift with Jib made in China here from our factory. If you have any enquiry about pricelist and quotation, please feel free to email us.

12m Vertical Reach with 6m Horizontal Outreach

The Mantall IMP120J combines the compact structure of a vertical mast lift with a jib system that provides additional horizontal access.

With a maximum working height of 12 m, a maximum platform height of 10 m and a maximum outreach of 6 m, IMP120J allows operators to reach elevated work points that may be difficult to access with a conventional vertical-only mast platform.

This combination makes the machine suitable for maintenance, installation and inspection tasks where obstacles or structures prevent the platform from being positioned directly beneath the work point.

Flexible Jib Movement

The jib section provides a swing range of:

-60° / +75°

This additional articulation increases platform positioning flexibility and allows the operator to approach elevated work points from different angles.

The jib design is particularly useful around building structures, industrial equipment and other obstacles where direct vertical access is limited.

345° Turntable Rotation with Zero Tail Swing

IMP120J features a 345° discontinuous turntable rotation.

The turntable has zero tail swing, helping reduce the rear clearance required when rotating the upper structure.

This configuration improves positioning capability in working areas where surrounding space is limited.

200kg Platform Capacity

The platform provides a rated lifting capacity of 200 kg and supports up to two persons according to the product specification.

Platform dimensions:

1.1 m × 0.8 m × 1.1 m

The aluminum alloy platform railing provides a practical working area for operators and necessary tools during elevated maintenance and installation tasks.

Self-Propelled Driving Performance

IMP120J is equipped with a self-propelled drive system for efficient movement between work locations.

Driving performance includes:

• Stowed driving speed up to 6 km/h
• Raised driving speed up to 0.7 km/h
• 25% gradeability
• 2WD × 2WS drive mode
• 0.75 m inside turning radius
• 2.6 m outside turning radius

The ability to move the machine efficiently between work positions helps improve productivity on sites requiring repeated aerial access.

AC Motor Drive

IMP120J adopts AC motor drive technology designed to reduce routine maintenance requirements.

The electrical drive system is powered by a 48V / 240Ah battery system and provides efficient self-propelled mobility for daily operation.

Compact Machine Width

Despite its working height and horizontal outreach, IMP120J has an overall stowed width of approximately 1.2 m.

Stowed dimensions:

4.03 m × 1.2 m × 1.99 m

The relatively narrow machine width helps improve access and maneuverability in industrial and commercial working areas.

Safety and Operating Functions

IMP120J incorporates multiple operating and safety functions for aerial work.

Standard features include:

• Proportional control
• Fault diagnosis system
• Emergency lowering system
• Emergency stop button
• Tilt sensor
• Drive at full height
• Automatic braking system
• Buzzer
• Fixed pothole guards
• Overload sensor
• Forklift and lifting holes
• Solid non-marking tires

Bidirectional Control

IMP120J provides control capability from both the platform and ground positions.

This arrangement supports convenient operation, inspection and emergency handling during aerial work.

Optional Features

Available optional configurations include:

• Fiberglass platform
• Motion alarm
• Tool box
• Top stop sensor
• Platform working light
• Air line to platform
• GPS
• Power socket to platform

Recommended Applications

The combination of 12 m working height and 6 m horizontal outreach makes IMP120J suitable for applications including:

• Industrial equipment maintenance
• Building facility servicing
• Electrical installation
• Lighting maintenance
• Warehouse facility inspection
• Mechanical installation
• Commercial building maintenance
• Elevated work around obstacles
• Production facility servicing

Why Choose IMP120J

IMP120J is particularly suitable for applications where vertical access alone is not sufficient.

Key advantages include:

• 12 m maximum working height
• 10 m maximum platform height
• 6 m maximum outreach
• 200 kg platform capacity
• 345° turntable rotation
• Zero tail swing
• -60° / +75° jib swing
• Self-propelled drive
• 6 km/h stowed driving speed
• 25% gradeability
• AC motor drive
• Proportional control
• Fault diagnosis system

Operating Safety

Always operate IMP120J within the specified platform capacity, tilt limits and operating conditions.

Operators should follow the operating manual and applicable local safety requirements when driving, rotating the turntable, positioning the jib and working at height.

Frequently Asked Questions

Q: What is the maximum working height of IMP120J?

A: IMP120J provides a maximum working height of 12 m and a maximum platform height of 10 m.

Q: What is the maximum horizontal outreach?

A: The maximum horizontal outreach is 6 m.

Q: How much can the platform carry?

A: IMP120J has a rated platform capacity of 200 kg and a maximum load number of two persons.

Q: How far can the turntable rotate?

A: The turntable provides 345° discontinuous rotation with zero tail swing.

Q: What is the jib movement range?

A: The jib provides a swing range of approximately -60° to +75°.

Q: Can IMP120J drive while elevated?

A: Yes. The specification lists a raised driving speed of up to 0.7 km/h, and drive-at-full-height is included in the standard features.

Q: What is the gradeability of IMP120J?

A: The machine provides 25% gradeability.
