XE80CT 8m Self-Propelled Crawler Electric Scissor Lift

Mantall Heavy Industry Co., Ltd. is one of the leading manufacturers and suppliers of XE80CT 8m Self-Propelled Crawler Electric Scissor Lift in China. We warmly welcome you to buy discount XE80CT 8m Self-Propelled Crawler Electric Scissor Lift made in China here from our factory. If you have any enquiry about pricelist and quotation, please feel free to email us.

When the Ground Is the Main Access Problem

Reaching the required working height is only one part of aerial work.

On outdoor jobsites, the first challenge may be getting the machine to the work position.

Loose ground, compacted soil, gravel, unfinished construction areas and changes in surface condition can make machine travel more difficult for conventional wheeled access equipment.

The Mantall XE80CT addresses this requirement with a self-propelled rubber crawler chassis.

Rubber Tracks Change How the Machine Travels

XE80CT uses rubber tracks instead of conventional solid wheels.

The track contact area distributes the machine load differently across the supporting surface and provides a crawler-style travel configuration for suitable outdoor and uneven-ground applications.

Current track specification:

Y200 × 72 – 49 links

The rubber track design is particularly relevant when the route to the work area is a key part of equipment selection.

40% Gradeability for Jobsite Transfer

The current XE80CT specification lists a maximum gradeability of 40%.

This provides useful travel capability when the machine needs to move across suitable ramps or changes in jobsite elevation.

Gradeability is a travel specification.

It does not mean that the platform should be raised while the machine remains on a 40% slope.

Before elevation, the machine must be positioned within the allowable operating and tilt limits stated in the operating manual.

0.15m Ground Clearance

XE80CT provides approximately 0.15 m center ground clearance.

Ground clearance becomes more important when equipment must travel across unfinished or irregular surfaces.

Combined with the crawler chassis, this helps make XE80CT more suitable for jobsite transfer conditions than equipment designed primarily for smooth finished floors.

Actual ground suitability should always be assessed before machine travel.

8m Working Height after Reaching the Work Area

Once the machine reaches the required position, XE80CT provides:

Maximum working height: 8 m

Maximum platform height: 6 m

This working range is suitable for many medium-height outdoor maintenance and construction-support tasks.

The key value of XE80CT is not simply the 8 m height.

It is the combination of that working height with tracked jobsite mobility.

0.9m Platform Outreach

The platform provides up to approximately 0.9 m horizontal outreach.

Platform dimensions are approximately:

1.84 m × 0.9 m × 1.1 m

The extension section carries up to 115 kg.

This allows the operator to adjust the working position for nearby service points without moving the tracked chassis after every minor change in location.

230kg Rated Platform Capacity

XE80CT provides a rated main-platform capacity of 230 kg.

Maximum platform occupancy is two persons.

The capacity is suitable for personnel together with normal tools and suitable servicing equipment within the rated load limit.

Main platform capacity: 230 kg

Extension capacity: 115 kg

Maximum persons: 2

Where Tracked Mobility Is Useful

XE80CT is particularly relevant when the access route includes surfaces such as:

• Compacted soil
• Suitable gravel areas
• Outdoor industrial yards
• Unfinished construction surfaces
• Landscape maintenance areas
• Uneven facility access routes
• Outdoor infrastructure sites

Ground conditions vary significantly between jobsites.

The operator should always assess surface firmness, slope and obstacles before travelling or elevating the machine.

Typical XE80CT Tasks

• Outdoor building maintenance
• Construction-site electrical work
• Industrial yard servicing
• Exterior lighting maintenance
• Infrastructure inspection
• Landscape facility maintenance
• Equipment installation on unfinished sites
• Outdoor plant maintenance

Travel First, Then Evaluate the Work Position

A useful way to select XE80CT is to divide the job into two questions.

First:

Can the machine safely travel from the unloading point to the work location?

Second:

Once there, does the 8 m working envelope cover the required task?

This is different from selecting indoor scissor lifts, where smooth-floor movement is often taken for granted.

For XE80CT, the travel route itself is an important part of equipment selection.

1.0m Machine Width

The stowed width of XE80CT is approximately 1.0 m.

Its stowed length is approximately 2.15 m.

This relatively compact tracked footprint can help when outdoor access routes have limited width.

Before ordering, customers should still confirm gate width, transport route, turning area and available machine clearance.

Electric Tracked Drive

XE80CT combines an electric power system with crawler travel.

Current specifications include:

• System voltage: 24 V
• Battery: 4 × 6 V, 235 Ah
• Power unit motor: 24 V / 2.2 kW
• Drive motor: 15 VAC / 1 kW

Electric operation makes the machine suitable for applications where a tracked access platform is required without relying on a conventional combustion-engine drive system.

Outdoor Operating Conditions

The current XE80CT specification lists a maximum wind speed of 12.5 m/s and maximum lateral force of 400 N.

The permitted maximum tilt is:

• Front / rear: 3°
• Side / side: 1.5°

These values define operating limits and should not be confused with the machine's 40% travel gradeability.

Elevated operation must remain within the manufacturer's specified conditions.

Before Sending XE80CT to the Jobsite

Confirm:

• Ground firmness
• Surface type
• Maximum slope along the travel route
• Required working height
• Required platform load
• Gate and access width
• Overhead obstacles
• Outdoor wind conditions
• Distance from unloading point to work area

This information helps determine whether a tracked scissor lift is appropriate for the actual project.

XE80CT Key Jobsite Data

• Maximum working height: 8 m
• Maximum platform height: 6 m
• Maximum outreach: 0.9 m
• Rated platform capacity: 230 kg
• Extension capacity: 115 kg
• Stowed width: 1.0 m
• Stowed length: 2.15 m
• Ground clearance: 0.15 m
• Gradeability: 40%
• Crawler size: Y200 × 72 – 49 links

FAQ

Q: Why choose a crawler scissor lift instead of a conventional wheeled scissor lift?

A: A crawler scissor lift is particularly relevant when the travel route includes suitable uneven, soft or unfinished ground where tracked mobility is useful.

Q: Can XE80CT work elevated on a 40% slope?

A: No. The 40% figure is the specified travel gradeability. Elevated operation must remain within the allowable machine tilt and operating limits.

Q: What is the maximum working height of XE80CT?

A: XE80CT provides an 8 m maximum working height and a 6 m maximum platform height.

Q: How many people can the platform carry?

A: The current specification lists a maximum of two persons with a rated main-platform capacity of 230 kg.
