Product features
The Mantall XDW series uses a diesel engine as its power source. Its powerful and excellent off-road performance allow users do aerial work even in the wild without being restricted by the power source.
Manufacturer
Mantall has more than 300 employees, production workers accounted for 70-80% of the total, cutting, bending, welding, assembly, polishing, painting, quality inspection, the whole process is complex and rigorous, Mantall depends on the basis of first phase of workshop, can realize the quantity production target for 300-350 per month, annual output of 3600-4200, at the same time, the second phase workshop of Mantall is under construction, aiming at increasing the scale of production at the same time guarantee the the quality of products.
Product details
Self-propelled Rough Terrain Scissor Lift XDW-series | |
Models | XDW150RT |
Working height max(m) | 15 |
Platform height max(m) | 13 |
(1)Platform height min(m) | 1.2 |
(2)Outreach(m) | 1.2 |
Lifting capacity(kg) | 680(single extension platform) |
570(double extension platform) | |
Lifting capacity(kg)(Extended platform) | 230 |
Weight(kg) | 6950 |
Platform size(L×W×H)m | 3.90×2.18×1.15 |
Extended length (m)(single extension platform) | 5.10 |
Extended length (m)(double extension platform) | 6.30 |
Skirting board height(m) | 0.15 |
Stowed size(L×W)m(single extension platform) | 4.47×2.29 |
Stowed size(L×W)m(double extension platform) | 3.97×2.29 |
Stowed length(m)(with outriggers) | 4.90 |
Height | 2.9 |
Folded Height(m) | 2.19 |
Wheelbase(m) | 2.80 |
Turn diameter(m) (inside) | 2.72 |
Turn diameter(m) (outside) | 5.93 |
Hydraulic tank capacity(L) | 115 |
Feul tank capacity(L) | 115 |
Gradeability | 45% |
Ground clearance(m) | 0.32 |
Control | Proportional control |
Drive | 4WD |
Drive height(m) | 9.6 |
Front to rear | 7° |
Left to right | 11° |
Raised time/Lowering time(s) | 80/90 |
Traction speed(km/h) | 6.4 |
Safe speed(km/h) | 1.0 |
Power source | Diesel |
Tire size(mm) | 33*12-20 |
Certificates
ISO9001/ISO14001/ISO18001 Certification
The people's Republic of China Liberation Army installed enterprise quality system certification
National Authorized production enterprise of explosion proof aerial work platform
The United Kingdom of SGS CE certification
Australia Design Review Certification AS1418.10
Product global liability insurance of China Ping An insurance Co., Ltd
Patent:
Until 2018, we had got more than 80 pcs National patents, 6 of them are Invention Patents
At present, Mantall have standard products over 80 models and each year we will accept over 10 models of customized products. For example, Outdoor wind resistant 10 level of the emergency signal tower, wind 12 offshore oil arm, aircraft maintenance equipment, etc.
FAQ
1. Which level of quality are your products?
We have got CE, ISO, SGS, TUV, SONCAP certificate so far.
2. What is the delivery time of your machine?
In general, the delivery time of our machine is about 30 days, customized machine will be delivered as the negotiation with our clients.
3. Can the machine be customized as our need, such as put on our logo?
Surely our machine can be customized as your need, Put on your logo is also available.
4. As the shipping period will take long time, how can you make sure the machine won’t be broken?
Our machine is film wrapped, to make sure the machine can be delivered to our customer smoothly, we will use the steel wire to fix the machine with the container.,
