Product Introduction
The XE65 75MINI series offers high performance with large turning angles, flexible operation in tight spaces, front wheel drive for stability, and double-sided doors for easy maintenance. It features long-lasting batteries, wide voltage adaptability, ample ground clearance, safety protection systems, and convenient maintenance, making it reliable and efficient for various indoor and outdoor working environments.
| Model | XE65MINI | XE75MINI |
| Dimension | ||
| Max. Working Height | 6.5m | 7.6m |
| A Max. Platform Height | 4.5m | 5.6m |
| B Max. Outreach | 0.6m | 0.6m |
| C Length Stowed | 1.48m | 1.48m |
| Length - Platform Extension | 1.97m | 1.97m |
| D Width Stowed | 0.81m | 0.81m |
| E Height Stowed (guardrails unfolded) | 2.06m | 2.16m |
| Height Stowed (guardrails folded) | 1.68m | 1.78m |
| F Wheelbase | 1.16m | 1.16m |
| Ground Clearance | 0.07m | 0.07m |
| Pothole protection board ground Clearance(down) | 0.02m | 0.02m |
| Platform Size(L×W×H) | 1.37m×0.7m×1.2m | 1.37m×0.7m×1.2m |
| Skirting Board Height | 0.15m | 0.15m |
| Performance | ||
| Max. Load number (indoor) | 2 pers | 2 pers |
| Lifting Capacity | 230kg | 230kg |
| Lifting Capacity (extended platform) | 120kg | 120kg |
| Drive Speed(Stowed) | 3km/h | 3km/h |
| Drive Speed(Raised) | 0.5km/h | 0.5km/h |
| Rising Time | 26s | 32s |
| Lowering Time | 21s | 27s |
| Gradeability | 25% | 25% |
| Turing Radius( inside/outside) | 0.45m/1.79m | 0.45m/1.79m |
| Tilt Sensor - Front to Back | 3° | 3° |
| Tilt Sensor - Side to Side | 1.5° | 1.5° |
| Tire Specification/ Type | 305mm×114mm | 305mm×114mm |
| Power | ||
| Drive Model | Hydraulic Drive, 2WD×2WS | Hydraulic Drive, 2WD×2WS |
| Power Unit Motor (voltage/power) | 24V/3.3KW | 24V/3.3KW |
| Hydraulic Tank Capacity | 4L | 4L |
| Battery Specifications | 2×12V/115Ah | 2×12V/115Ah |
| Control Voltage | 24V | 24V |
| Charger (Input Voltage/Output Current) | 100-240V/15A | 100-240V/15A |
| Weight | ||
| Weight | 990kg | 1266kg |
| Standard | GB/CE | GB/CE |
